Transportation

Secure. Fast. Always On. For Every Mile

INDUSTRY OVERVIEW
Modern transportation networks depend on intelligent systems to ensure safety, efficiency, and passenger satisfaction。 From train control units and PIS displays to video surveillance and ticketing kiosks, reliable storage is essential to keep data flowing。 Industrial-grade SSDs and DRAM modules deliver the stability, longevity, and temperature resistance needed to operate smoothly across rail, road, and urban mobility platforms。 Even in the face of constant vibration and wide temperature swings。



KEY CHALLENGES

1. Extreme Environments
Storage must withstand shock, vibration, humidity, and fluctuating temperatures in and outside the vehicle。

2. System Longevity
Transportation systems often operate for over a decade, requiring long product life cycles and stable supply。

3. Real-Time Data Integrity
From live video feeds to control commands, secure and lossless data handling is non-negotiable。



SOLUTIONS

< CF Card >

• SLC : Up to 64 GB   /  2DpSLC: Up to 128 GB  /  MLC  : Up to 256GB
• Read/Write Performance: 137 / 95 MB/s
• Supports Std. & Ind. Temp Range, Write Protect, Quick Erase。

< CFast >

• 3DTLC : Up to 1TB   /  3DpSLC: Up to 128 GB
• Read/Write Performance: 550 / 495 MB/s
• Supports Std. & Ind. Temp Range, Write Protect, Power Loss Protection (3DTLC : Up to 960GB   /  3DpSLC: Up to 320 GB)

< 2.5" SATA SSD >

• 3DTLC : Up to 15.36 TB   /  3DpSLC: Up to 1.92 GB
• Read/Write Performance: 550 / 530 MB/s
• Supports Std. & Ind. Temp Range, Write Protect,, Thermal Throttling, TCG OPAL Encryption. Power Loss Protection (3DTLC : Up to 7.92 TB   /  3DpSLC: Up to 1.92 GB)

< PCIe M.2 2280 >

• 3DTLC : Up to 4TB  /  3DpSLC : Up to 1.92GB
• Read/Write Performance: 3,300 / 1,000 MB/s
• Supports Std. & Ind. Temp Range, Write Protect, Thermal Throttling, TCG OPAL Encryption, Power Loss Protection (3DTLC : up to 1920GB)

< PCIe Gen 5x4 15mm U.2 >

• DWPD 1: Up to 30.72 TB   /  DWPD 3: Up to 25.60 TB
• Sequential Read/Write: 14,000 / 7,500 MB/s
• Supports Dual/Single Port, Power Loss Protection, Thermal Throttling, TCG OPAL Encryption。

< mSATA >

• 3DTLC : Up to 2 TB  /  3DpSLC : Up to 640 GB
• Read/Write Performance: 550 / 510 MB/s
• Supports Std. & Ind. Temp Range, OPAL Encryption. Power Loss Protection (3DTLC : Up to 2 TB   /  3DpSLC: Up to 640 GB)

< SD Card >

• SLC : Up to 2 GB  /  MLC : Up to 8 GB  /  2DpSLC : Up to  4 GB  /  3DTLC : Up to 512 GB  /  3DpSLC : Up to 128 GB
• Read/Write Performance: 95 / 85 MB/s
• Supports Std. & Ind. Temp Range，

< MicroSD Card >

• SLC : Up to 2 GB  /  MLC : Up to 16 GB  /  2DpSLC : Up to  8 GB  /  3DTLC : Up to 512 GB  /  3DpSLC : Up to 128 GB
• Read/Write Performance: 95 / 85 MB/s
• Supports Std. & Ind. Temp Range。

Why Choose UD info ?
With a great experience in industrial storage, UD info is trusted by global partners for delivering reliable, high-performance SSD and DRAM solutions tailored to demanding environments。 From industrial-temperature support to long product lifecycles and customizable setting, our products are built to meet the real-world needs of embedded, edge, and enterprise applications。 Backed by responsive technical support and flexible service, UD info is your dependable partner for industrial-grade memory。
